Tecsun PL-365 radio

TECSUN PL-365 is a PLL DSP radio receiver for listening to FM, Longwave (LW), AM / Medium Wave (MW) and Shortwave (SW) frequency bands and is Single Sideband (SSB) capable.

This device uses DSP si4735 micro-chips (from Silicon Labs in USA) to digitize the analog radio signal. In combination with the PLL (Phase-Locked Loop) circuitry, this greatly improves the radio's sensitivity, selectivity, S/N ratio and anti-interference capability.

PL-365 is also equipped with Easy Tuning Mode (ETM), Tecsuns own designed tuning method. ETM provides the user the possibility to auto-scan for new radio stations, without replacing stations that are already stored into the radios memory. ETM is an ideal feature for users who listen to radio broadcastings at different locations.

• PL-365 radio
• Tecsun stereo earphones
• USB charging cable
• Tecsun carrying pouch
• Tecsun MW/LW antenna with 3.5mm plug
• Tecsun AN-04U wire antenna
• English manual

• ETM: Easy Tuning Mode: Auto-scan for new radio stations, without replacing existing stored memories. Newly found stations will be temporarily stored into the ETM memory.
• SSB (USB / LSB)
• Belt-clip
• MW/LW external antenna socket (3.5mm)


Frequency Range

• FM: 76 - 108 MHz
  • 76 - 108MHz
  • 87 - 108MHz
  • 87.5 - 108MHz

• MW (AM): 520 - 1710 kHz
  • 522 - 1620kHz (tuning steps of 9 kHz)
  • 520 - 1710kHz (tuning steps of 10 kHz)

• LW: 150- 520 kHz

• SW: 1711 – 29999 kHz

Tuning Methods

• Easy Tuning Mode (ETM)
• Auto Tuning Storage (ATS) for FM / MW / LW /SW
• Jog dial manual Tuning
• Auto-scan

Basic Features

• Signal strength and S/N ratio indication
• Temperature display (°C or °F)
• Clock & Alarm (24 hour format)
• 550 station memories
• Telescopic antenna (45.5 cm / 18 inches)
• Alarm by radio
• Automatically alarm stopper (1 - 90 minutes)
• Sleep timer (1 - 120 minutes)
• FM Mono/Stereo selection
• LCD backlight (auto-off after 5 seconds)
• Keylock function
• Volume with 30 sound levels
• Speaker (16Ω, 0.5W)
• Belt-clip
• Stereo earphone socket (3.5mm)
• MW/LW antenna socket (3.5mm)
• DC 5V mini-USB jack
• Built-in charging system for 3 x AA Ni-MH batteries

 Power / Charging

• Battery power:  3 x AA-size batteries
• DC power (for FM only): 5V
• Charging/Power: DC 5V / 250mA
• Built-in charging system to charge Ni-MH rechargeable batteries

Unit Size

• 53 x 159 x 26 mm (L x H x W)

Specifications


• Sensitivity
  • FM (S / N = 30dB) < 3uV
  • MW (S / N = 26dB) < 1mV/m
  • LW (S / N = 26dB) < 10mV/m
  • SW (S / N = 26dB) < 30uV
  • SSB (S / N = 10dB) < 3uV

• Selectivity:
  • FM > 60dB
  • MW / LW > 60dB
  • SW > 60dB
