S-2000
S2000
$289.00 inc. tax
Color*
S2000 Power Supply*
S-2000 Summary

S-2000


Tecsun HAM Receiver

AM/FM/LW/SW/SSB/AIR



Special Functions:


Dual Conversion for LW, MW and SW


Single Side Band(SSB) with Upper Side Band (USB) and Lower Side Band (LSB)

360 degrees rotatable MW antenna

Air Band (VHF):

For intercepting radio communication in aviation – e.g. commercial and general aviation, radio navigational aids, air traffic control.By using your PL-660s air band function, you may intercept communication between pilots and the air traffic control, but also other communication from commercial and general aviation, radio navigational aids and air traffic control.

Squelch Control for Quality FM and Air Band Listening





Frequency Range:



FM: 76 - 108MHz / 87.5 - 108MHz


MW:

522 - 1620kHz (band step 9kHz)

520 - 1710kHz (band step 10kHz)



LW:    100KHz - 519kHz

SW:    1711KHz - 29999kHz

AIR:    118 - 137MHz




Tuning Methods:


Auto Tuning Storage (ATS)

Auto-scan tuning

Jog dial manual tuning

Direct keypad entry of a frequency




Basic Features:



FM stereo via earphones or headphones.

1000 station memories (100 each for FM, SW, SSB & Air Band;  50 each for MW & LW;  500 for mixed band)

24 hours clock & dual alarm clock function (alarm by either radio broadcasting or buzzer)

Sleep timer function

Extra-long telescopic antenna for FM, SW, Air Band.

External or internal FM /MW antenna switch

Antenna attenuation to enhance reception.

Wide / narrow bandwidth selection

RF Gain Control knob

455 kHz IF output jack for DIY (Synchronous Detection, DSP Demodulator, DRM Converter)

High-quality built-in 4” speaker with excellent sound effect.

Line-in socket (can be used as speaker for MP3)

Line-out socket (radio broadcasting can be transferred to other device)



Power supply: 4D alkaline batteries (included). Also AC or DC power selectable: 220V AC power cord, 120V DC Adaptor or 230V DC adaptor.

Unit size 372 x 183 x 153 mm (L x H x W) (including front handle)




Specification:


Sensitivity


LW band (S/N = 26dB) < 3mV/m

MW band (S/N = 26dB) < 0.35mV/m

SW band (S/N = 26dB) < 18μV


SSB (S/N = 10dB) < 1μV

AIR (S/N = 10dB) < 5μV

FM band (S/N = 30dB) < 3μV




Selectivity (AM)


Wideband±10kHz,   Greater than 40dB


Narrowband±5kHz,  Greater than 60dB




FM Stereo Crosstalk


Better than 30dB




Signal to Noise Ratio


MW:   greater than 45dB

SW:   greater than 50dB

FM:    greater than 60dB




IF Frequency


SSB/ AM:

1st IF: 55.845MHz

2nd IF:455kHz



FM:

1st IF: 10.7MHz (Single Conversion)




Image Rejection


MW / LW / SW:


55.845MHz:      Greater than 90dB


455kHz:           Greater than 80dB



AIR:      Greater than 90dB


FM:       Greater than 60dB




IF Rejection


AM:

55.845MHz:      Greater than 60dB

455kHz:           Greater than 60dB


FM:

10.7MHz:          Greater than 100dB




AGC Performance


AGC range:  Wider than 80dB

Threshold: 12μV




RF Gain


20dB




Antenna Attenuation


Three levels:  0dB,-10dB,-20dB




Internal Antenna


1200 mm telescopic whip (for use on FM, AIR, SW and SSB bands)

Ferrite rod antenna φ10 x 120 mm (HQ) (for use from 100 kHz through 1800kHz)




External Antenna Input


SW:      50Ω (BNC type),   500Ω

FM:       50Ω (BNC type)

AIR:      50Ω (BNC type)




IF Output


IF: 455kHz

Signals output greater than 60mV, when input greater than 3μV




Line Audio Output


Stereo left and right

300Mv, 4.7kΩ for each output




Earphone Jack


φ3.5mm, 8 ~ 32Ω, stereo type




Internal Speaker


8Ω / 2W, φ100mm



Brand:
Tecsun
weight:
300001
Product Condition:
New
Bulk Buying Options
single:
$289.00
2 up to 5:
$250.00
per item
